Manufactured from High Quality fine-grain QSt/E Steel
Front mounting without Headstock
Hydraulic drive for a volume flow of 70 - 120 l/min, with integrated over run clutch
Hydraulic spool valves required:
1 x pressure flow
1 x pressure less return flow (max. counter-pressure <5 bar)
1 x oil leakage line to the hydraulic tank (max. counterpr. < 2 bar)
Belt protection with tension measuring slot
High tempered M Hammer flails to ensure clean cut and maximum shredding using less power
Spiral Rotor with specially formed flail lugs to protect against damage from obstacles, bearings protected against dirt, tear
and tear
Patented removable shredding bar – System: "Shark fin"
Support roller for adjusting height of mulcher
Side, wearing skids
High tempered spring steel one way protection flaps in front of the mower hood
